Genaral Technology
standard:IEEE802.3ab 1000Base-T,IEEE802.3z 1000Base-SX/LX
Gigabit ethernet,IEEE802.1qVLAN,IEEE802.1p QoS,IEEE802.1d Spanning Tree
One RJ45 connector:connected to STP/UTP,category-5 twisted pair
one fiber port:Multi-mode SC (fiber size:50,62.5/125 um)
single mode SC/FC (fiber size:9/125 um)
Transmission distance
Dual-fiber multi-mode:220m(62.5/125 um)/550m(50/125um)
Dual-fiber single-mode:25/40/60/80 Km
Single-fiber single-mode:25/40 Km
Category-5 twisted pair:100m
LED Indicator
PWR(Power suply),FX LINK (optical link action),
TP LINK 1000(twisted pair link 1000M),
TP LINK 100 (twisted pair 100M),
TP ACT(twisted pair packet forwarding)
Power supply
Power:AC 220 0.5A/DC-48 (built-in)
Power consumption:5W
Environmnet
Operating temperature:-10~55`C
Operating humidity:5%~90%
Maintaioning temperature:-40~70`C
Relative Humidity:5%~90%(no condensation)
Ordering information:
Part No. | Descriptions | Remark |
HD-210S-10A | Gigabit Ethernet 10/100/1000Mbps WDM Media Converter 10km SC (Tx = 1310nm) | SC/FC/ST Available |
HD-210S-10B | Gigabit Ethernet 10/100/1000Mbps WDM Media Converter 10km SC (Tx = 1550nm) | SC/FC/ST Available |
HD-210S-20A | Gigabit Ethernet 10/100/1000Mbps WDM Media Converter 20km SC (Tx = 1310nm) | SC/FC/ST Available |
HD-210S-20B | Gigabit Ethernet 10/100/1000Mbps WDM Media Converter 20km SC (Tx = 1550nm) | SC/FC/ST Available |
HD-210S-40A | Gigabit Ethernet 10/100/1000Mbps WDM Media Converter 40km SC (Tx = 1310nm) | SC/FC/ST Available |
HD-210S-40B | Gigabit Ethernet 10/100/1000Mbps WDM Media Converter 40km SC (Tx = 1550nm) | SC/FC/ST Available |
HD-210S-60A | Gigabit Ethernet 10/100/1000Mbps WDM Media Converter 60km SC (Tx = 1490nm) | SC/FC/ST Available |
HD-210S-60B | Gigabit Ethernet 10/100/1000Mbps WDM Media Converter 60km SC (Tx = 1550nm) | SC/FC/ST Available |
