Overview (CISCO2911-SEC/K9)

The Cisco 2900 series integrated services router offers embedded hardware encryption acceleration, voice- and video-capable Digital Signal Processor (DSP) slots, intrusion prevention, call processing, voice mail, and application services. CISCO2911-SEC/K9 is almost the same as CISCO2911, except that it offers Security bundle.

Quick Specs

Figure 1 shows the front view of CISCO2911-SEC/K9.

CISCO2911-SEC/K9

Table 1 shows the Quick Specs of the CISCO2911-SEC/K9.

Product Code

CISCO2911-SEC/K9

Bundle

Security Bundle w/SEC license PAK

Rack Units

2RU

Interfaces

3 integrated 10/100/1000 Ethernet ports (RJ-45 only)

Expansion Slot(s)

1 service module slot

1 Internal Service Module slot

2 onboard digital signal processor (DSP) slots

4 enhanced high-speed WAN interface card slots

RAM

512 MB (installed) / 2 GB (max)

Flash Memory

256 MB (installed) / 8 GB (max)

Dimensions

43.8 cm x 30.5 cm x 8.9 cm

Package Weight

16.15 Kg

Product Details

Figure 2 shows the ports on the back panel of CISCO2911-SEC/K9.

CISCO2911-SEC/K9 Back Ports

Note:

① EHWIC slots 0, 1, 2, and 3 (0, Far right)                                ⑧ AC, DC, AC-POE, or DC-POE Power Module

② USB serial port                                                                           ⑨ RJ-45 serial console port

③ AUX                                                                                              ⑩ 10/100/1000 Ethernet port (GE0/1)

④ 10/100/1000 Ethernet port (GE0/2)                                        ⑪ USB 0

⑤ 10/100/1000 Ethernet port (GE0/0)                                        ⑫ USB 1

⑥ CompactFlash 0 and 1 (0, Right)                                            ⑬ Ground

⑦ Service module slot 1

Figure 3 shows the LEDs on the back panel of CISCO2911-SEC/K9.

CISCO2911-SEC/K9 Back LEDs

Note:

① CompactFlash 0 and 1 (0, Far right)

② ISM ⑥ S (Speed)

③ PVDM3

     PVDM 0, 1, (0, Far right LED) ⑦ L (Link)

④ EN (Enable USB console)

⑤ EN (Enable RJ-45 console)

The Modules and Cards

Table 2 shows some recommended modules and cards for this router.

Models

Description

SM-ES3G-16-P

Enhanced EtherSwitch Service Module, L2/L3 switching, 16* 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology

SM-ES3G-24-P

Enhanced EtherSwitch Service Module, L2/L3 switching, 24 * 10/100/1000 GE ports, Enhanced POE, Cisco EnergyWise technology

VWIC3-2MFT-G703

Cisco Voice/WAN Card VWIC3-2MFT-G703

HWIC-2T

2-Port Serial WAN Interface Card Cisco Router High-Speed WAN Interface card

EHWIC-1GE-SFP-CU

Cisco 1900, 2900, 3900 Router EHWIC WAN Card EHWIC-1GE-SFP-CU

EHWIC-4ESG

Four port 10/100/1000 Base-TXGigabit Ethernet switch interface card for Cisco1900 2900 3900Routers

ISM-SRE-300-K9

Internal Services Module (ISM) with Services Ready Engine

PVDM3-16

16-channel high-density voice DSP module

MEM-CF-256U1GB

256MB to 1GB Compact Flash Upgrade for Cisco 1900,2900,3900

MEM-CF-256U2GB

256MB to 2GB Compact Flash Upgrade for Cisco 1900,2900,3900

MEM-CF-256U512MB

256MB to 512MB CF Upgrade for Cisco 1900,2900,3900 ISR

MEM-CF-256U4GB

256MB to 4GB Compact Flash Upgrade for Cisco 1900,2900,3900

MEMUSB-1024FT

1GB USB Flash Token
